ATS Diesel Triplelok Torque Converter Factory Stall Speed 1994 To 2007 5.9L Cummins Dodge 47R-H/47-Re/48-Re Transmission - 3029302164 ATS Diesel Triplelok Torque Converter Factory Stall Speed 1994 To 2007 5.9L Cummins Dodge 47R-H/47-Re/48-Re Transmission ATS Diesel Triplelok Torque Converter Factory Stall Speed 1994 To 2007 5.9L Cummins Dodge 47R-H/47-Re/48-Re Transmission ATS Diesel Triplelok Torque Converter Factory Stall Speed 1994 To 2007 5.9L Cummins Dodge 47R-H/47-Re/48-Re Transmission
ATS Diesel Triplelok Torque Converter Factory Stall Speed 1994 To 2007 5.9L Cummins Dodge 47R-H/47-Re/48-Re Transmission - 3029302164

ATS Diesel Triplelok Torque Converter Factory Stall Speed 1994 To 2007 5.9L Cummins Dodge 47R-H/47-Re/48-Re Transmission

SKU
226128
Availability
Normally ships within 1-2 business days.
$1,187.50
Free Shipping

ATS diesel performance has been a well recognized name in the pickup truck landscape for more than twenty years. The company creates innovative products for commercial fleets to personal trucks. It offers a full range of repair and service for its customer’s diesel pickups (light duty). Whether a customer is looking for long term reliability or improving overall performance, ATS Diesels products are the way to go. The company provides all the necessary parts for diesel transmission and engines making sure that trucks are able to not only survive but thrive in the toughest of environments. ATS diesel manufactures, designs, invents, and distributes in Arvada, Colorado. ATS provides its customers with the most reliable and finest off road, racing, and towing products for trucks.

Available individually is the ATS TripleLok Torque Converter. This torque converter is built to handle daily driving and towing duties while delivering reliable performance.

The ATS TripleLok utilizes an optimized factory stall speed that features improved torque multiplication. With factory torque multiplication at approximately 1.25:1, the ATS TripleLok increases it to 2.0:1. This occurs when peak engine torque is achieved. Increased torque multiplication results in improved vehicle response, towing and driving ability.

Every TripleLok comes standard with a 5 year / 500,000 mile warranty. When the most efficient torque converter is required, look no further than the ATS TripleLok Torque Converter.
Details:

  • TripleLok Torque Converter
  • Factory Stall Speed
  • Patented Viskus Clutch Drive System for increased efficiency
  • Billet Cover with Patented Square Flank Drive
  • Square Tab Construction (Not Round)
  • Viskus Disc CNC Laser Cut Clutch Plates
  • Billet Piston with Patented Flank Drive Tab design
  • Proprietary ATS exclusive Clutch Formulation with unique bonding technology (ensures 100 percent chemical Bond)
  • Redesigned Spring Dampener supports increased torque loads
  • 4340 hardened turbine splines provide longevity and reliability
  • Fully welded turbine and impeller vanes
  • Custom Stator with high flow windows increase oil flow, providing increased efficiency
  • Full roller bearing construction between high load areas
  • 4340 CNC cut pump drive hub locked into impeller housing
  • Plasma welded for unsurpassed strength
  • Sold Individually
  • SKU: 3029302164

Fits:

  • 1994-2007 Dodge Ram 2500|3500 Truck w/5.9L Cummins Engine and Chrysler 47R-H|47-RE|48-RE Transmission

Specifications:

Warranty: 5-Year/500,000 Mile Limited Warranty
Core Charge: $400
Location: Front
Application: Competition
Material: Billet Steel
Make: Dodge Diesel
Core Type: Single

Fitment & Application:

    More Information
    BrandATS Diesel
    Part NumberATS-3029302164
    Shipping MethodUPS/FedEx/USPS Ground
    AvailabilityNormally ships within 1-2 business days.
